tomas®-abutment tube square 22
tomas®-abutment double tube 1.5
300
Anchorage systems
Instruments and accessories
(coupling element with tube)
Abutment with rotatable square tube for direct coupling between the tomas®-pin and various appliances,
e.g. for intrusion etc.
Inner F tube Width tube REF Quantity
0.56 x 0.70 mm / 22 x 28 4.0 mm 302-025-22 1 piece
Concept by Dr. Sohani
(coupling element with 2 tubes)
Abutment with rotatable double tube for direct coupling between tomas®-pin and various appliances,
e.g. for bi- or unilateral mesialization, distalization, intrusion etc.
The tomas®-abutment U-wire (REF 302-025-21) can be used in addition.
Inner ø tube Width tube REF Quantity
1.55 mm / 61 2 x 3.0 mm 302-025-30 1 piece
tomas®-abutment U-wire
(coupling element with wire)
Abutment with rotatable bilateral wire for direct coupling between the tomas®-pin and various appliances,
e.g. for bi- or unilateral mesialization, distalization etc.
The tomas®-abutment double tube 1.5 (REF 302-025-30) can be used in addition.
Wire ø Wire length REF Quantity
1.10 mm / 43 2 x 80 mm 302-025-21 1 piece
tomas®-abutments median
Combination of tomas®-abutment U-wire (REF 302-025-21) and tomas®-abutment double tube 1.5
(REF 302-025-30). Combination is intended for two tomas®-pins which are placed sagitally to the
mid-palatal suture. The distance between the tomas®-pins must be at least 6 mm.
Inner ø tube Width tube Wire ø Wire length REF Quantity
1.55 mm / 61 2 x 3.0 mm 1.10 mm / 43 2 x 80 mm 302-025-51 1 piece
tomas®-abutment wire 6
(coupling element with wire)
Abutment with rotatable unilateral wire for direct coupling between the tomas®-pin and various appliances,
e.g. for bi- or unilateral mesialization, distalization etc. The tomas®-abutment tube 1.1 (REF 302-025-11)
can be used in addition.
Wire ø Wire length REF Quantity
1.10 mm / 43 60 mm 302-025-06 1 piece
