Banding technique
136
Buccal tubes
Ortho-Cast 18/22
non-convertible ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16 - 14° 10° • 4.0 mm 724-232-00
Ortho-Cast 18/22
Ortho-Cast 18/22
Ortho 18/22
Maxilla Mandible Maxilla + Mandible
McLaughlin-Bennett-
Trevisi**
26-27 - 14° 10° • 4.0 mm 724-233-00
McLaughlin-Bennett-
Trevisi**
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16/36-37 0° 6° • 4.0 mm 724-092-00 724-094-00
26-27/47-46 0° 6° • 4.0 mm 724-093-00 724-095-00
17-16/26-27/47-46/36-37 0° 6° 4.0 mm 724-090-00 724-091-00
Slot 18: 0.46 x 0.64 mm / 18 x 25
Slot 22: 0.56 x 0.70 mm / 22 x 28
** The Dentaurum version of this prescription is not claimed to be a duplication of any other, nor
does Dentaurum imply that it is endorsed in any way by Drs. McLaughlin, Bennett and Trevisi.
single rectangular
convertible ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16 - 10° 8° • 4.0 mm 724-048-00
26-27 - 10° 8° • 4.0 mm 724-049-00
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
47-46 - 20° 0° • 4.0 mm 724-234-00
McLaughlin-Bennett-
Trevisi**
for the 1st molar
36-37 - 20° 0° • 4.0 mm 724-235-00
McLaughlin-Bennett-
Trevisi**
for the 1st molar
47-46 - 25° 8° • 4.0 mm 724-040-00
36-37 - 25° 8° • 4.0 mm 724-041-00
Slot 18: 0.46 x 0.64 mm / 18 x 25
** The Dentaurum version of this prescription is not claimed to be a duplication of any other, nor
does Dentaurum imply that it is endorsed in any way by Drs. McLaughlin, Bennett and Trevisi.
non-convertible ∙ distal notch ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16/36-37 0° 6° • 3.3 mm 724-607-00 724-610-00
26-27/47-46 0° 6° • 3.3 mm 724-608-00 724-611-00
17-16/26-27/47-46/36-37 0° 6° 3.3 mm 724-609-00 724-612-00
Slot 18: 0.46 x 0.64 mm / 18 x 25
Slot 22: 0.56 x 0.70 mm / 22 x 28
non-convertible ∙ distal extension ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16/36-37 0° 0° • 6.0 mm 725-164-00 725-166-00
Ricketts® Universal 18,
Standard Edgewise
26-27/47-46 0° 0° • 6.0 mm 725-165-00 725-167-00
Ricketts® Universal 18,
Standard Edgewise
17-16/36-37 0° 6° • 6.0 mm 725-168-00 725-170-00
26-27/47-46 0° 6° • 6.0 mm 725-169-00 725-171-00
Slot 18: 0.46 x 0.64 mm / 18 x 25
Slot 22: 0.56 x 0.70 mm / 22 x 28
