single rectangular
135
Buccal tubes
Ortho-Cast M-Series 18/22
Ortho-Cast M-Series 18/22
Maxilla Mandible Maxilla + Mandible
Banding technique
non-convertible ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16 - 14° 10° • 3.3 mm 818-212-10 822-212-10
McLaughlin-Bennett-
Trevisi**
26-27 - 14° 10° • 3.3 mm 818-212-20 822-212-20
McLaughlin-Bennett-
Trevisi**
17-16 - 10° 8° • 3.3 mm 818-217-10 822-217-10
26-27 - 10° 8° • 3.3 mm 818-217-20 822-217-20
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
47 - 10° 0° • 3.3 mm 818-512-40 822-512-40
McLaughlin-Bennett-
Trevisi**
37 - 10° 0° • 3.3 mm 818-512-30 822-512-30
McLaughlin-Bennett-
Trevisi**
47-46 - 25° 8° • 3.3 mm 818-217-40 822-217-40
36-37 - 25° 8° • 3.3 mm 818-217-30 822-217-30
47-46 - 30° 12° • 3.3 mm 818-218-40 822-218-40
36-37 - 30° 12° • 3.3 mm 818-218-30 822-218-30
Slot 18: 0.46 x 0.64 mm / 18 x 25
Slot 22: 0.56 x 0.70 mm / 22 x 28
** The Dentaurum version of this prescription is not claimed to be a duplication of any other, nor
does Dentaurum imply that it is endorsed in any way by Drs. McLaughlin, Bennett and Trevisi.
convertible ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16 - 14° 14° • 3.3 mm 818-111-10 822-111-10 Roth
26-27 - 14° 14° • 3.3 mm 818-111-20 822-111-20 Roth
17-16 - 14° 10° • 3.3 mm 818-112-10 822-112-10
McLaughlin-Bennett-
Trevisi**
26-27 - 14° 10° • 3.3 mm 818-112-20 822-112-20
McLaughlin-Bennett-
Trevisi**
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
47-46 - 30° 4° • 3.3 mm 818-111-40 822-111-40 Roth
36-37 - 30° 4° • 3.3 mm 818-111-30 822-111-30 Roth
47-46 - 20° 0° • 3.3 mm 818-112-40 822-112-40
McLaughlin-Bennett-
Trevisi**
for the 1st molar
36-37 - 20° 0° • 3.3 mm 818-112-30 822-112-30
McLaughlin-Bennett-
Trevisi**
for the 1st molar
Slot 18: 0.46 x 0.64 mm / 18 x 25
Slot 22: 0.56 x 0.70 mm / 22 x 28
** The Dentaurum version of this prescription is not claimed to be a duplication of any other, nor
does Dentaurum imply that it is endorsed in any way by Drs. McLaughlin, Bennett and Trevisi.
