Bonding technique
130
Buccal tubes
Ortho-Cast M-Series 18/22
convertible ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
16 - 14° 14° • 3.3 mm 818-121-16 822-121-16 Roth
26 - 14° 14° • 3.3 mm 818-121-26 822-121-26 Roth
16 - 14° 10° • 3.3 mm 818-122-16 822-122-16
Ortho-Cast 18/22
Ortho-Cast 18/22
Maxilla Mandible Maxilla + Mandible
McLaughlin-Bennett-
Trevisi**
26 - 14° 10° • 3.3 mm 818-122-26 822-122-26
McLaughlin-Bennett-
Trevisi**
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
46 - 30° 4° • 3.3 mm 818-121-46 822-121-46 Roth
36 - 30° 4° • 3.3 mm 818-121-36 822-121-36 Roth
46 - 20° 0° • 3.3 mm 818-122-46 822-122-46
McLaughlin-Bennett-
Trevisi**
36 - 20° 0° • 3.3 mm 818-122-36 822-122-36
McLaughlin-Bennett-
Trevisi**
Slot 18: 0.46 x 0.64 mm / 18 x 25 · Slot auxiliary tube: 0.46 x 0.64 mm / 18 x 25
Slot 22: 0.56 x 0.70 mm / 22 x 28 · Slot auxiliary tube: 0.46 x 0.64 mm / 18 x 25
** The Dentaurum version of this prescription is not claimed to be a duplication of any other, nor
does Dentaurum imply that it is endorsed in any way by Drs. McLaughlin, Bennett and Trevisi.
double rectangular
non-convertible ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16 - 10° 15° • 4.0 mm 724-280-51
26-27 - 10° 15° • 4.0 mm 724-281-51
Slot 18: 0.46 x 0.64 mm / 18 x 25 · Slot auxiliary tube: 0.46 x 0.64 mm / 18 x 25
non-convertible ∙ with vertical hook ∙ Quantity: 10 pieces
Teeth Torque Distal Offset Hook Width REF (18) REF (22) System
17-16/26-27/47-46/36-37 0° 0° • 3.5 mm 724-018-51 724-019-51
Ricketts® Universal 18,
Standard Edgewise
Slot 18: 0.46 x 0.64 mm / 18 x 25 · Slot auxiliary tube: 0.46 x 0.64 mm / 18 x 25
Slot 22: 0.56 x 0.70 mm / 22 x 28 · Slot auxiliary tube: 0.56 x 0.70 mm / 22 x 28
