Zirconium oxide blanks
138
CAD/CAM materials
Nacera® Pearl Shaded 16+2
ø 98.3 mm
Colored, highly translucent zirconium oxide in 16 V-Classic colors and two bleach colors.
Advantages & indications:
• for multiple indications – highly stable while highly translucent, meeting all demands
• shade and process stability thanks to homogeneous coloring, ensuring consistent color results
• economic solution, as the dipping process and the use of coloring liquids are no longer necessary
• excellent machinability without fracturing or chipping
• delivers flawless monolithic restorations with a natural aesthetic
• extremely high-precision fitting thanks to Instant Fit Process (I.F.P.)
Norm: DIN EN ISO 6872
Color REF (14 mm) REF (18 mm) REF (25 mm) REF (12 mm) REF (16 mm) REF (20 mm) Quantity
OM2 270-009-14 270-009-18 270-009-25 1 piece
OM3 270-010-14 270-010-18 270-010-25 1 piece
A1 270-011-14 270-011-18 270-011-25 270-011-12 270-011-16 270-011-20 1 piece
A2 270-012-14 270-012-18 270-012-25 270-012-12 270-012-16 270-012-20 1 piece
A3 270-013-14 270-013-18 270-013-25 270-013-12 270-013-16 270-013-20 1 piece
A3,5 270-014-14 270-014-18 270-014-25 270-014-12 270-014-16 270-014-20 1 piece
A4 270-015-14 270-015-18 270-015-25 1 piece
B1 270-021-14 270-021-18 270-021-25 270-021-12 270-021-16 270-021-20 1 piece
B2 270-022-14 270-022-18 270-022-25 270-022-12 270-022-16 270-022-20 1 piece
B3 270-023-14 270-023-18 270-023-25 1 piece
B4 270-024-20 1 piece
C1 270-031-14 270-031-18 270-031-12 270-031-16 270-031-20 1 piece
C2 270-032-14 270-032-18 270-032-12 270-032-16 270-032-20 1 piece
C3 270-033-14 270-033-18 270-033-25 1 piece
C4 270-034-20 1 piece
D2 270-042-14 270-042-18 270-042-25 270-042-12 270-042-16 270-042-20 1 piece
D3 270-043-14 270-043-18 270-043-12 270-043-16 270-043-20 1 piece
D4 270-044-20 1 piece
Technical data
Material ZrO2 3Y-TZP
4 point flexural strength 1200 MPa
Radioactivity < 0.02 Bq/g
Solubility < 10 μg/cm2
CTE 10 x 10-6 K-1
The values listed were measured on test samples and are typical for
the material. The product properties may, however, deviate from these
values depending on the component design and the forming process.
