CAD/CAM materials
Zirconium oxide blanks
ceraMotion® Z Cubic Multishade
ø 98.3 mm
Multi-shaded, pre-shaded and ultra-highly translucent zirconium oxide for inlays, veneers, single crowns
and 3-unit bridges. Suitable for all open CAD/CAM systems.
Advantages and indications:
• reliable reproducibility for high-level aesthetics
• natural, smooth shade transition from cervical to incisal
• available in the 9 most popular V-shades
• particularly suitable for inlays, onlays, monolithic crowns and 3-unit bridges
• excellent machinability
• translucency 49 % (non-shaded, 1 mm)
• optimum finishing with ceraMotion® One Touch and veneering with ceraMotion® Zr
Recommended sintering temperature: 1450 °C / 2642 °F
Norm: DIN EN ISO 6872
Color REF (14 mm) REF (18 mm) REF (22 mm) Quantity
A1 272-311-14 272-311-18 272-311-22 1 piece
A2 272-312-14 272-312-18 272-312-22 1 piece
A3 272-313-14 272-313-18 272-313-22 1 piece
A3,5 272-315-14 272-315-18 272-315-22 1 piece
A4 272-314-14 272-314-18 272-314-22 1 piece
B1 272-321-14 272-321-18 272-321-22 1 piece
B2 272-322-14 272-322-18 272-322-22 1 piece
C2 272-332-14 272-332-18 272-332-22 1 piece
D2 272-333-14 272-333-18 272-333-22 1 piece
Technical data
Material ZrO2 5Y-PSZ
Bending strength 600 MPa
Density > 6.04 g/cm³
Radioactivity < 0.02 Bq/g
Solubility < 100 μg/cm2
CTE 10.5 x 10-6 K-1
The values listed were measured on test samples and are typical for
the material. The product properties may, however, deviate from these
values depending on the component design and the forming process.
