Técnica de bandas
rectangulares dobles
138
Tubos bucales
Ortho-Cast M-Series 18/22
convertible ∙ Tubo auxiliar desplazado en bucal gingival ∙ Cantidad: 10 piezas
Dientes Torque Distal Offset Ganchos Anchura REF (18) REF (22) Sistema
47-46 - 30° 4° • 3,6 mm 818-151-40 822-151-40 Roth
36-37 - 30° 4° • 3,6 mm 818-151-30 822-151-30 Roth
47-46 - 20° 0° • 3,6 mm 818-152-40 822-152-40
Ortho-Cast 18/22
Ortho-Cast 18/22
Ortho-Cast 18/22
Maxilar Mandíbula Maxilar + Mandíbula
McLaughlin-Bennett-
Trevisi** para el 6
36-37 - 20° 0° • 3,6 mm 818-152-30 822-152-30
McLaughlin-Bennett-
Trevisi** para el 6
Slot 18: 0,46 x 0,64 mm / 18 x 25 · Slot tubo auxiliar: 0,46 x 0,64 mm / 18 x 25
Slot 22: 0,56 x 0,70 mm / 22 x 28 · Slot tubo auxiliar: 0,46 x 0,64 mm / 18 x 25
** The Dentaurum version of this prescription is not claimed to be a duplication of any other, nor
does Dentaurum imply that it is endorsed in any way by Drs. McLaughlin, Bennett and Trevisi.
no convertible ∙ Cantidad: 10 piezas
Dientes Torque Distal Offset Ganchos Anchura REF (18) REF (22) Sistema
17-16 - 9° 10° • 4,0 mm 724-066-00 724-166-00
26-27 - 9° 10° • 4,0 mm 724-067-00 724-167-00
Dientes Torque Distal Offset Ganchos Anchura REF (18) REF (22) Sistema
47-46 - 22° 12° • 4,0 mm 724-064-00 724-164-00
Ricketts® 18 - IV.
Dimension para el 6
36-37 - 22° 12° • 4,0 mm 724-065-00 724-165-00
Ricketts® 18 - IV.
Dimension para el 6
Slot 18: 0,46 x 0,64 mm / 18 x 25 · Slot tubo auxiliar: 0,46 x 0,64 mm / 18 x 25
Slot 22: 0,56 x 0,70 mm / 22 x 28 · Slot tubo auxiliar: 0,56 x 0,70 mm / 22 x 28
no convertible ∙ con gancho vertical ∙ Cantidad: 10 piezas
Dientes Torque Distal Offset Ganchos Anchura REF (18) REF (22) Sistema
47-46/36-37 - 30° 0° • 4,0 mm 724-616-00 724-617-00
Dientes Torque Distal Offset Ganchos Anchura REF (18) REF (22) Sistema
17-16/26-27/47-46/36-37 0° 0° • 3,5 mm 724-018-00 724-019-00
Ricketts® Universal 18,
Standard Edgewise
Slot 18: 0,46 x 0,64 mm / 18 x 25 · Slot tubo auxiliar: 0,46 x 0,64 mm / 18 x 25
Slot 22: 0,56 x 0,70 mm / 22 x 28 · Slot tubo auxiliar: 0,56 x 0,70 mm / 22 x 28
convertible ∙ Cantidad: 10 piezas
Dientes Torque Distal Offset Ganchos Anchura REF (18) REF (22) Sistema
47-46 - 25° 8° • 4,0 mm 724-056-00 724-156-00
36-37 - 25° 8° • 4,0 mm 724-057-00 724-157-00
Slot 18: 0,46 x 0,64 mm / 18 x 25 · Slot tubo auxiliar: 0,46 x 0,64 mm / 18 x 25
Slot 22: 0,56 x 0,70 mm / 22 x 28 · Slot tubo auxiliar: 0,46 x 0,64 mm / 18 x 25
